Air Displacement: 6.35cfm(180L/min).

Maximum Free Air Delivery: 4.7cfm(130L/min).

Maximum Pressure: 116psi(8bar).

Ideal for use where an oil free air delivery is required.

Especially suited to small' low pressure touch-up and air brush spraying applications.

Simple construction with fewer components makes this unit practically maintenance-free.

Reduced weight gives greater portability and can be transported and even operated on its side.

Precision welded receiver tank manufactured to meet Pressure Vessel Directive.

Fitted with fully automatic pressure cut-out switch and air regulator with gauge.

Specification:

• Model No SAC02415
• Air Displacement cfm(L/min): 6.35(180)
• Brand: Sealey
• Maximum Free Air Delivery cfm(L/min): 4.7(130)
• Maximum Pressure: 116psi(8bar)
• Minimum Rated Supply: 13A
• Motor Output: 1.5hp
• Nett Weight: 16.0kg
• Outlet: Quick Release Coupling
• Phase: 1ph
• Receiver Capacity: 24L
• Size (W x D x H): 570 x 300 x 600mm
• Speed: n/a
• Supply: 230V/13A

• Instructions:
• Parts Diagram:
