• V-Belt Extend
• Part No: V13X950
• Material: Polychloropren (neoprene)
• Colour: Black
• Width (mm): 17
• Length (mm): 1030
• Outer Length (mm): 1038
• Rotation angle (°): 36
• Qty: 1



• Fibre loaded rubber material provides excellent heat and wear resistance.
• Molded notch construction provides reduced bending stresses around small pulleys.
• Form grinding provides a smooth contact point between the belt surface and the pulleys.



• Suitable with:
• CHEVROLET
• COLORADO
•  Diesel 2.5L/81KW 2.5 Rear-Wheel Drive 4JA1 Rear-Wheel Drive Ute (01/04-12/12)



• ISUZU
• D-MAX
•  Diesel 2.5L/74KW 2.5 DiTD 4x4 (TFS54) 4JA1-TC TFR,TFS All-wheel Drive Ute (05/02-06/12)
•  Diesel 2.5L/58KW 2.5 CRDi (TFR86J, TFR54J) 4JA1-L TFR,TFS Rear-Wheel Drive Ute (06/12-10/16)
•  Diesel 2.5L/74KW 2.5 DiTD (TFR86_, TFR54_) 4JA1-TC TFR,TFS Rear-Wheel Drive Ute (10/02-06/12)
•  Diesel 2.5L/58KW 2.5 CRDi 4JA1-L TFR,TFS Rear-Wheel Drive Platform/Chassis (10/13-06/18)



• ELF
•  Diesel 2.8L/42KW 2.8 D 4JB1 NHR5_ Rear-Wheel Drive Platform/Chassis (10/85-09/03)
•  Diesel 2.8L/42KW 2.8 D 4JB1 NHR5_ Rear-Wheel Drive Van (10/85-09/03)
•  Diesel 2.8L/57KW 2.8 TD 4JB1-T NHR5_ Rear-Wheel Drive Platform/Chassis (10/85-09/92)
•  Diesel 2.8L/57KW 2.8 TD 4JB1-T NHR5_ Rear-Wheel Drive Van (10/85-09/92)



• TRAVIZ
•  Diesel 2.5L/57KW 2.5 (PHR54) 4JA1 Rear-Wheel Drive Platform/Chassis (11/19-on)



• Caution:
• Before any service work on the belt is begun to be sure that the motor or engine is switched off and cannot be started.



• Important:
• Check for worn tensioners and idler pulleys. This is the best time to replace these part these parts if needed.



• Belt Removal:
• Loosen adjustment or pivot bolts.
• Move adjustment unit to minimum position.
• Remove belt.



• Belt Installation:
• Place new belt looseley on pulleys. Do not pry onto pulleys.
• Tension belt according to manufacturer's instruction.
• Run drive 5 minutes and retension. Belts must be tight enough to prevent slippingwhen drive is fully loaded.
